[move-stdlib] Introduce efficient OrderedMap implementation #14872

igor-aptos · 2024-10-04T18:01:26Z

Description

Implement efficient OrderedMap implementation in move-stdlib, to replace/deprecate SimpleMap. It is an in-memory datastructure - i.e. doesn't store anything in separate resources.

Implementation is a SortedVectorMap, but given the efficiency improvements of vector operations with memcpy, it's performance characteristics are extremely good.

Running different sizes tests (these are full results), we get milliseconds needed for 100 inserts and 100 removals on maps of different sizes:

num elements  SimpleMap       OrderedMap::SortedVectorMap
10            6.4             6.8
100           25.4            10.3
1000          673.9           12.8
10000         too long        19.5

Basically achieving log(n) performance, with very simple implementation.

How Has This Been Tested?

provided unit tests

Key Areas to Review

Type of Change

New feature

Which Components or Systems Does This Change Impact?

Aptos Framework

Checklist

I have read and followed the CONTRIBUTING doc
I have performed a self-review of my own code
I have commented my code, particularly in hard-to-understand areas
I identified and added all stakeholders and component owners affected by this change as reviewers
I tested both happy and unhappy path of the functionality
I have made corresponding changes to the documentation

trunk-io · 2024-10-04T18:01:30Z

⏱️ 4h 32m total CI duration on this PR

Slowest 15 Jobs	Cumulative Duration	Recent Runs
execution-performance / single-node-performance	1h 41m	⬜ 🟥 🟥 🟥 🟥
execution-performance / test-target-determinator	17m	🟩 🟩 🟩 🟩 🟩
rust-move-unit-coverage	16m	🟩
rust-move-unit-coverage	14m	🟩
test-target-determinator	14m	🟩 🟩 🟩 🟩
rust-move-unit-coverage	14m	🟩
rust-cargo-deny	14m	🟩 🟩 🟩 🟩 🟩 (+3 more)
rust-move-unit-coverage	11m	🟩
rust-move-unit-coverage	10m	🟩
rust-move-unit-coverage	9m	🟩
check-dynamic-deps	8m	🟩 🟩 🟩 🟩 🟩 (+4 more)
rust-move-tests	4m	🟥
semgrep/ci	4m	🟩 🟩 🟩 🟩 🟩 (+5 more)
rust-move-tests	4m	🟥
rust-move-tests	4m	🟥

🚨 2 jobs on the last run were significantly faster/slower than expected

Job	Duration	vs 7d avg	Delta
execution-performance / single-node-performance	37m	16m
test-target-determinator	3m	4m

_{settings ⋅ feedback ⋅ docs ⋅ learn more about trunk.io}

lightmark · 2024-10-04T18:10:59Z

aptos-move/framework/aptos-stdlib/sources/data_structures/ordered_map.move

+/// Uses cmp::compare for ordering, which compares primitive types natively, and uses common
+/// lexicographical sorting for complex types.
+module aptos_std::ordered_map {
+    // friend aptos_std::big_ordered_map;


will be uncommented in the PR with big_ordered_map

lightmark · 2024-10-04T18:11:38Z

aptos-move/framework/aptos-stdlib/sources/data_structures/ordered_map.move

+    /// The OrderedMap datastructure.
+    enum OrderedMap<K, V> has drop, copy, store {
+        /// sorted-vector based implementation of OrderedMap
+        SortedVectorMap {


codecov · 2024-10-04T18:12:37Z

Codecov Report

All modified and coverable lines are covered by tests ✅

Project coverage is 57.4%. Comparing base (41a0b13) to head (76e0b76).

Additional details and impacted files

@@                 Coverage Diff                  @@
##           igor/native_compare   #14872   +/-   ##
====================================================
  Coverage                 57.4%    57.4%
====================================================
  Files                      859      859
  Lines                   211663   211663
====================================================
  Hits                    121527   121527
  Misses                   90136    90136

☔ View full report in Codecov by Sentry.
📢 Have feedback on the report? Share it here.

lightmark · 2024-10-04T18:30:53Z

aptos-move/framework/aptos-stdlib/sources/data_structures/ordered_map.move

+        let len = self.entries.length();
+        let index = binary_search(key, &self.entries, 0, len);
+        assert!(index < len, error::invalid_argument(EKEY_NOT_FOUND));
+        let Entry { key: old_key, value } = self.entries.remove(index);


vector does not keep the order here? IIRC, it swap and pop_back. Did you change that behavior?

remove keeps the order. swap_remove doesn't

lightmark · 2024-10-04T18:32:13Z

aptos-move/framework/aptos-stdlib/sources/data_structures/ordered_map.move

+    /// Aborts with EKEY_ALREADY_EXISTS if key already exist.
+    public fun add<K, V>(self: &mut OrderedMap<K, V>, key: K, value: V) {
+        let len = self.entries.length();
+        let index = binary_search(&key, &self.entries, 0, len);


we should introduce iterator to vector too so you don't need to know the length anymore for assertion.

this seems fine to me

lightmark · 2024-10-04T18:32:48Z

aptos-move/framework/aptos-stdlib/sources/data_structures/ordered_map.move

+    /// Changes the key, with keeping the same value attached to it
+    /// Aborts with EKEY_NOT_FOUND if `old_key` doesn't exist.
+    /// Aborts with ENEW_KEY_NOT_IN_ORDER if `new_key` doesn't keep the order `old_key` was in.
+    public(friend) fun replace_key_inplace<K: drop, V>(self: &mut OrderedMap<K, V>, old_key: &K, new_key: K) {


just curious, any use case for this

seems not generally useful, but in BTreeMap keys here represent max_key of a child subtree, and so I need to modify it in place.

lightmark · 2024-10-04T18:34:39Z

aptos-move/framework/aptos-stdlib/sources/data_structures/ordered_map.move

+            return;
+        };
+
+        // TODO: can be implemented more efficiently, as we know both maps are already sorted.


https://leetcode.com/problems/merge-two-sorted-lists/

yeah, but issue is here we have vectors, not lists, and so how to do it in-place, without moving too many elements.

Easiest is to can either create a new vector, populate, and then swap (I'll probably just do that)

if "vector" here had capacity, I could start from the end, without temporary storage, but I don't have a way to create empty values here (i.e. have this work without value being drop+copy)

lightmark · 2024-10-04T18:41:01Z

aptos-move/framework/aptos-stdlib/sources/data_structures/ordered_map.move

+            f(iter.iter_borrow_key(self), iter.iter_borrow(self));
+            iter = iter.iter_next(self);
+        }
+        // vector::for_each_ref(


what's wrong here?

entry is not a public type, so when this get's inlined in the caller, it cannot do compile.

basically inline functions need to be implemented only using public API.

I can remove this snippet as well

lightmark · 2024-10-04T18:42:04Z

aptos-move/framework/aptos-stdlib/sources/data_structures/ordered_map.move

+
+    // return index containing the key, or insert position.
+    // I.e. index of first element that has key larger or equal to the passed `key` argument.
+    fun binary_search<K, V>(key: &K, entries: &vector<Entry<K, V>>, start: u64, end: u64): u64 {


Can we make a standard Entry and implement binary search only once?

I am writing binary search only once.

If you mean for binary search to be reusable, so other's don't need to write it, maybe that should be an inline function in vector

Moving Entry to a standard separate file, makes all field accesses to require getter and setter functions, not sure that's best

lightmark

amazing work! Thanks @igor-aptos . You are the hero!
