title author
Exercise 3 Transferring and sharing data
Matt Pritchard

Exercise 3: Transferring and sharing data

Scenario

I want to copy some code from my own machine to my home directory on JASMIN. I also want to copy some data to a Group Workspace on JASMIN so that I can share it with colleagues. My colleagues and I all belong to the workshop Group Workspace.

Objectives

After completing this exercise I will be able to:

  • Copy a small text file from my local machine to my JASMIN home directory using a transfer server.
  • Copy a directory tree of data files recursively from my local machine to the workshop group workspace.
  • Understand permissions and ownership needed for group access.
  • Be aware of the limitations of some transfers methods.
  • Pull in data from an external data source using a transfer server

JASMIN resources

  • Account with valid jasmin-login privilege
    • If you are using one of the training accounts this will have been set up for you
  • Transfer server: xfer[12].jasmin.ac.uk (1 or 2)
  • Home directory: /home/users/train050 (replace with your username)
  • workshop group workspace at /gws/pw/j05/workshop

Local resources

  • Local machine set up as per exercise 0, with:
    • SSH client application (use a command-line client for this exercise: you won't need the graphical desktop)
    • SSH key and JASMIN credentials
    • suitable network connection
  • Directory on your local machine: /Users/fredbloggs/ (choose your own)

Videos

You can follow this exercise by watching the videos below, or by following the text of this article, or a combination of both.
Task
Solutions & Discussion

Instructions

  1. Make a simple text file or script on your local machine
  2. Copy it to your home directory on a jasmin transfer server
  3. Make a directory on your local machine and create a few simple files in it (representing some data that you want to share). This is the source directory.
  4. Make a destination directory for yourself within the workshop group workspace
  5. Copy the the source directory and its contents to the destination directory using the transfer server
  6. Check that the ownership and permissions on your directory within the group workspace allow reading, and, if you choose, writing, by other members.
  7. Using command line tools, download a test file from http://speedtest.tele2.net/100MB.zip to your destination directory in the workshop group workspace, then delete it.

Review

This exercise demonstrates how to use a transfer server to:

  • Copy small files such as source code/scripts to your home directory
  • Copy data to a group workspace
  • Check permissions on the data to make sure it’s visible by collaborators
  • Download some data from an external data source

We have looked at some basic methods suitable for small datasets or where speed is not critical. For larger data transfers or over longer distances (international/intercontinental), it is recommended to consider other available options which could be more efficient, depending on source & destination. See exercise 10 or consult the documentation here

Alternative approaches and best practice

  • In addition to scp, alternative tools sftp and rsync also enable simple data transfer.
  • We have seen that rsync can be used to synchronise a local and remote directory: it can be configured to only copy those data that are new or have changed: more efficient if you're running it repeatedly.
  • sftp is very useful and is also the underlying protocol used in many third-party tools.
  • rclone can be configured to interace with various storage backends, including an SFTP server (like the transfer server used above), and can do synchronisation like rsync. It also talks to a whole variety of other storage backends such as cloud and object storage.
  • Please don't install DropBox or other file-sharing software on JASMIN.
  • Some third-party tools exist which provide graphical interfaces for transfers using sftp, e.g. FileZilla, CyberDuck. These are applications which you can install on your own machine, to talk to JASMIN via the protocols it supports.
  • Some editors (e.g. VS Code) have extensions which enable you to setup SSH connections to edit & save files remotely. This can be useful for editing files on JASMIN, but from the convenience of your own local desktop environment.
  • NONE of the SSH-based transfer methods we have looked at perform well for large volumes of data or over long distances. Define "large" or "long"?
  • see ex10 for advice about:
    • More efficient data transfers for large data / longer distances
    • Automated transfers
    • Transfers within JASMIN

Questions to test yourself

All too easy? Here are some questions to test your knowledge an understanding. You might find the answers by exploring the JASMIN Documentation

  1. How would you set the permissions on a file/directory so that it can be

    • written by any other member of the workspace?
    • readable by any user of JASMIN?

    NOTE: NEVER set permissions so that a file or directory is readable and writable by everyone (777). This is not safe.

  2. How could you share data on JASMIN with users outside of JASMIN?

  3. Why are transfer methods based on SSH not very efficient over long distances?

Cheatsheet

  1. Make a small text file on your local machine containing a bash script which you could run on JASMIN.

    $ echo "This is a readme file" > README.txt
$ scp README.txt [email protected]:~/

    The echo command makes the text file for us. Use some other small file if you have one handy, or create one in your favorite text editor on your local machine. We then copy it using the scp command, specifying our home directory ~/ as the path.

    Log into the xfer server itself, to see the file that you copied in place in the destination directory:

    $ ssh -A [email protected]
$ pwd
$ ls -l README.txt

  2. Make a small tree of directories on your local machine and create 2 files somewhere in those directories.

    $ mkdir -p mydata/01 mydata/02
$ echo "This is a test file" > mydata/01/file01.txt
$ echo "This is also a test file" > mydata/02/file02.txt

    Check what you have created:

    $ find mydata
mydata
mydata/02
mydata/02/file02.txt
mydata/01
mydata/01/file01.txt

    Make yourself a directory in the workshop group workspace: First log in to the transfer server: (substitute train050 for your own JASMIN username). You may find it useful to open another terminal window for this (don't forget to check first whether your SSH key is loaded: see exercise 01 ).

    $ ssh -A [email protected]

    Go to the workspace directory and make your own user directory there:

    $ cd /gws/pw/j05/workshop
$ ls
users

    We have set out the GWS so that it has a directory called users where you can make your own sub-directories for working through these exercises. This helps keep things orgnanised. Make a directory for yourself, named as per your account username:

    NOTE: Below, we use the $USER environment variable which contains your JASMIN username.

    NOTE: We will clear out these directories, and the home directories of the training accounts, after each workshop event. Normally you will have ~48hrs after the end of the workshop event to collect any data or code which you may want to keep. If you are working through these exercises outside of an organised event, please clean up after yourself and do not expect these data to persist.

    $ echo $USER             # check what is held in this environment variable
$ mkdir users/$USER      # make a directory for yourself underneath the "users" directory
$ ls -ld users/$USER      # check what you have created: note the ownerhsip & permissions
drwxr-sr-x 2 train050 gws_workshop 4096 Jan 26 11:26 users/train050

    Back on your local machine, recursively copy the directory using scp: (replace train050 with your username)

    scp -r mydata [email protected]:/gws/pw/j05/workshop/users/train050/

    In your other terminal window on (or log back in to) the transfer server, inspect your destination directory:

    $ cd /gws/pw/j05/workshop/users/$USER
$ find .
./mydata
./mydata/02
./mydata/02/file02.txt
./mydata/01
./mydata/01/file01.txt

    The find command just shows the structure. To examine the permissions, use ls -l, or ls -lR to show the child directories too:

    mydata:
total 0
drwxr-xr-x 1 train050 gws_workshop 0 Dec  4 11:59 01
drwxr-xr-x 1 train050 gws_workshop 0 Dec  4 12:02 02

mydata/01:
total 0
-rw-r--r-- 1 train050 gws_workshop 20 Dec  4 11:59 file01.txt

mydata/02:
total 0
-rw-r--r-- 1 train050 gws_workshop 25 Dec  4 11:59 file02.txt

    While there are plenty of good tutorials out there on UNIX permissions, let's talk about how they affect things on JASMIN.

    These permissions may be what we want, but let's close them down for now, then work out how to open them up to people we want to share our data with:

    Try the following command, which will restrict the group and world permissions on everything in the mydata directory and below:

    $ chmod -R go-rX mydata         # note capital X
$ ls -lR mydata
mydata:
total 128
drwx------ 2 train050 gws_workshop 4096 Feb 23 10:51 01
drwx------ 2 train050 gws_workshop 4096 Feb 23 10:51 02

mydata/01:
total 48
-rw------- 1 train050 gws_workshop 20 Feb 23 10:51 file01.txt

mydata/02:
total 48
-rw------- 1 train050 gws_workshop 25 Feb 23 10:51 file02.txt

    The directories 01 and 02 are signified by the extra d at the start, but all the files and directories have 3 sets of permissions: User, Group and wOrld (u, g, o). We are also told about which user and what group they belong to.

    drwx------ 1 train050 gws_workshop 0 Dec  4 11:59 01
 rwx         : user
    ---      : group
       ---   : world

    This tells us that directory 01 belongs to user train050 and group gws_workshop. Its user permissions are rwx (read, write, execute) but its group and world permissions are now not set (---).

    If we want to open up directory 01 so that members of the same group gws_workshop can read it, but non-members still can't, we could set the group read permission. For directories, we need to add the x or execute permission as well: the capital X in the command means that it will work out the right change to make for files and directories:

    $ chmod -R g+rX mydata/01
$ ls -lR mydata
mydata:
total 0
drwxr-x--- 1 train050 gws_workshop 0 Dec  4 11:59 01
drwx------ 1 train050 gws_workshop 0 Dec  4 12:02 02

mydata/01:
total 0
-rw-r----- 1 train050 gws_workshop 20 Dec  4 11:59 file01.txt

mydata/02:
total 0
-rw------- 1 train050 gws_workshop 25 Dec  4 11:59 file02.txt

    Here, we've changed the permissions on a directory recursively, i.e. including everything beneath it as well. You can modify the permissions on a file or set of files individually, but bear in mind they will also be affected by any directories they sit in.

    Note that the group ownership of a file or directory in a group workspace might be different from any files you've created in your home directory. Check the permissions on the README.txt file you wrote there earlier:

    $ ls -l ~/README.txt
-rw-r--r-- 1 train050 users 22 Feb 23 10:48 /home/users/train050/README.txt

    By default, files you create in your home directory belong to group users (which is the default group for all users with jasmin-login privilege). You can check what groups you belong to with the groups command:

    $ groups
users open gws_workshop

    Normally, the top-level directory of a group workspace is set so that files and directories created beneath them inherit the group ownership of the top-level directory, but this can be over-ridden. If for some reason you've got files which belong to the users group, then the group permissions which are set on those files are affected by whether a user belongs to that group instead, so you might need to change them to belong to the gws_workshop group first.

    You can do this with the chgrp command, and it can be used recursively on a directory to change all the items in a directory tree (...but you have to have the right permissions to be able to modify them!)

    $ chgrp -R gws_workshop mydata

  3. Using command line tools or a script you have written, download a test file from http://speedtest.tele2.net/100MB.zip, then delete it.

    We can use either curl or wget to fetch a remote data file via HTTP from within JASMIN. These utilities are installed on the transfer servers.

    The speed test site http://speedtest.tele2.net/ provides a number of different files which can be used to test download performance, but also to test the functionality of any tools to check they're working properly.

    $ wget http://speedtest.tele2.net/100MB.zip

    Followed by this to delete the file:

    $ rm 100MB.zip

    We're deleting the file straight after downloading it, so an alternative is to specifying the output file as the null device, which means it's not actually written to storage:

    $ wget -O/dev/null http://speedtest.tele2.net/100MB.zip
$ wget -O/dev/null http://speedtest.tele2.net/100MB.zip
--2020-12-04 12:38:16--  http://speedtest.tele2.net/100MB.zip
Resolving speedtest.tele2.net (speedtest.tele2.net)... 90.130.70.73, 2a00:800:1010::1
Connecting to speedtest.tele2.net (speedtest.tele2.net)|90.130.70.73|:80... connected.
HTTP request sent, awaiting response... 200 OK
Length: 104857600 (100M) [application/zip]
Saving to: ‘/dev/null’

100%[==============================================================================>] 104,857,600  179MB/s   in 0.6s

2020-12-04 12:38:16 (179 MB/s) - ‘/dev/null’ saved [104857600/104857600]

    Here, we've got a result of 179MB/s which is pretty good. All sorts of factors can contribute to slow transfer performance but this apprach can be helpful in eliminating this particular machine as the bottleneck. Quite often the reason is a slow server at the other end, or complex directory structures full of small files which slow things down. For more discussion of transfer performance, see ex10.

    The equivalent using curl would be:

    $ curl -o /dev/null http://speedtest.tele2.net/100MB.zip
% Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                Dload  Upload   Total   Spent    Left  Speed
100  100M  100  100M    0     0   195M      0 --:--:-- --:--:-- --:--:--  196M

    Both wget and curl are very useful, feature-rich transfer tools and can do a lot more than shown here: read the relevant man pages for more information. You can also build your own transfer tools using packages such as requests in Python (see ex10)

Answers to questions

  1. How would you set the permissions on a file/directory so that it can be
  • written by any other member of the workspace?
  • readable by any user of JASMIN?

You can first check the existing permissions on a file with:

$ ls -l myfile.txt
-rw-r--r-- 1 train050 gws_workshop 0 Jan 22 17:01 myfile.txt

The group "read" permission is already set: this is the second "r", whereas the user permissions are currently set to rw, i.e. read and write.

You can add group write permission by a command such as:

$ chmod g+rw myfile.txt

or numerically with

$ chmod 664 myfile.txt

Check again:

$ ls -l myfile.txt
-rw-rw--r-- 1 train050 gws_workshop 0 Jan 22 17:01 myfile.txt

Now we can see that the second set of permissions also has the w permission for write. You'd need to do similar for directories, but remember that for directories you also need to set the x (execute) permission.

By default, the top-level directory of the GWS is set so that new child directories inherit the fact that they're owned by the same group: gws_workshop as opposed to users, which would otherwise be the default (a file which you create in your home directory would normally belong to group users). But you still might need to set the permissions on the file to control what can be done with the file by other members of the same group.

Talk to your Group Workspace manager about how they would like users to organise their data and keep things tidy: it's their responsibility to set policies like this for the group.

  1. How could you share data on JASMIN with users outside of JASMIN?

Using the logic above, you could set the permissions on the file/directory so that they're "world-readable" ...but can the outside "world" see the file? Not by default. File systems on JASMIN aren't visible outside of JASMIN, and can't be mounted remotely.

This can be arranged, however:

  • Ask your Group Workspace manager to consider requesting that the GWS is set up with a public area which is shared via HTTP. This means that the data below that public directory is openly available to anyone on the internet with a HTTP client such as a browser or a tool like wget or curl. That can be a good way of disseminating results and small amounts of data to external collaborators who are not users of JASMIN. But this should be used with care, and must not be used for hosting a project web site: that's not what that service is for.

  • Using Object Storage could provide more flexible sharing options: use of this is something your GWS manager would need to discuss with the JASMIN team.

  1. Why are transfer methods based on SSH not very efficient?

For the interested reader, see ESnet's resources about faster data transfers including some reasons why scp should be avoided over WAN: to do with a buffer of limited size built in to the software stack that they're built on.

Tools like BBCP, GridFTP and Globus Online can help with more efficient use of available bandwidth and give much better performance for moving large volumes of data. See our documentation on Data Transfer Tools. For short-distance transfers (by "distance" here we mean a network round-trip-time of <20ms), scp and other SSH-based tools can still be a good choice, for convenience and ease of use if nothing else.
